People ask me what the Leitra velomobile I ride is like under the fairing. Here are two pictures of the frame that I took last time I was doing maintenance on the bike and had all the fairing pieces and seat removed.
From the front, you can see the two piece, carbon fiber leaf springs for the front two wheels. The “Y” shaped bit at the very front is where the front fairing attaches and pivots for entry and exit. The seat snaps into the frame just ahead of the rear wheel. In the center of the back of the bike is the rear wheel which sits inside a wraparound fender that keeps water, snow and dirt out of the seating area.
From the rear, you can see the Bionx electric motor assist. It consists of the linear motor hub in the middle of the rear wheel and the battery mounted under the left arm rest. The cargo area of the fairing sits above the rear wheel on the rack-like extension. The “V” shaped parts in the middle of the rack and two small strips on either side of the rear wheel are carbon fiber leaf springs for the rear wheel.
The frame is hard to pickup and put on a work stand, so I usually just hang it from my work stand with a loop of rope as shown. This lets me turn the rear wheel and adjust the derailer and lube the chain.
